| Dimensions (mm)
|
| Overall length |
3210 |
| Ground length (transportation) |
1420 |
| Overall height (to top of boom) |
1340 |
| Overall width |
950/1200 |
| Overall height (to top of cab) |
2230 |
| Counterweight ground clearance |
445 |
| Minimum ground clearance |
150 |
| Tail swing radius |
640 |
| Wheelbase |
1100 |
| Standard track shoe width |
200 |
| Bucket width |
430 |
| RS Boom right swing |
49.7° |
| LS Boom left swing |
62.7° |
| Working range (mm)
|
| Max. digging height |
2800 |
| Max. dumping height |
1850 |
| Max. digging depth |
2100 |
| Max. digging radius on ground |
3550 |
| Min. swing radius of working device |
1540 |
| Max. lifting height of bulldozer |
150 |
| Max. cutting depth of bulldozer |
220 |
